Auto High Beam Assist (AHBA) – JLR Retrofit

Product Overview

Auto High Beam Assist (AHBA) is a genuine Jaguar Land Rover advanced lighting assistance system engineered to improve night-time visibility and reduce glare for other road users. The forward-facing camera, integrated into the rear-view mirror assembly, continuously scans the road ahead. The system identifies headlamps from oncoming vehicles and tail lamps from preceding traffic. It also evaluates ambient street lighting levels to determine when high beam operation is appropriate. The system activates high beam automatically when ambient light falls below the defined threshold and no other light sources are detected. It immediately dips to low beam when it recognises active vehicle lighting ahead. High beam resumes once those light sources exit the camera detection zone.

Our lr-retrofit AHBA retrofit replicates the factory JLR operating logic. You will see the official AHBA tell-tale on the instrument cluster when the system is active. The driver retains full override control through the vehicle’s existing lighting stalk, which maintains the original JLR user interface. This retrofit works alongside your vehicle’s existing headlamp hardware and body control module after successful coding and calibration.

System Operation & Technical Specification

The AHBA camera module captures real-time visual data and sends processed signals to the vehicle lighting control module over the JLR CAN network. The system will only enable automatic high beam functions when the vehicle travels above the calibrated speed threshold and ambient light conditions satisfy activation criteria. The camera differentiates between vehicle lighting and static roadside light sources such as street lamps, road signs and reflective markers. This intelligence prevents unnecessary high beam deactivation in lit urban environments.

Correct windscreen condition is critical for reliable AHBA operation. The camera requires an unobstructed view through the designated windscreen zone. Windscreen damage, tint film or dirt within the camera field of view will degrade detection performance. Our technicians validate camera alignment and complete end-to-end functional testing after installation. We verify high beam activation, low beam dip response and instrument cluster warning indicators before handover.

Retrofit Package Scope

• Genuine JLR AHBA forward camera / mirror assembly as required for your vehicle model
• Targeted wiring harness installation to match factory JLR routing standards
• JLR diagnostic programming, ECU configuration and AHBA feature activation
• Camera calibration and road test validation
• System demonstration covering driver controls, cluster indicators and operating limits

Compatible JLR Vehicles

Our AHBA retrofit supports most modern Jaguar and Land Rover platforms including Range Rover, Range Rover Sport, Range Rover Velar, Discovery, Discovery Sport, Evoque, I-Pace, XE, XF and XJ. Contact our technical team with your VIN to confirm hardware compatibility and exact component requirements before booking. Some vehicles require additional wiring or module updates to support AHBA integration.

Order & Technical Enquiry

Submit your VIN and vehicle details via our enquiry form to receive a tailored quotation for AHBA retrofit. Our JLR trained technical team reviews your vehicle configuration and confirms lead times, parts availability and appointment scheduling. All work follows JLR technical procedures to preserve vehicle electrical integrity and maintain ADAS system reliability.
