Park Assist Retrofit for Land Rover & Jaguar

Park Assist turns a difficult manoeuvre into a straightforward, repeatable procedure. The system measures a candidate space as you drive past, confirms the geometry and then steers your vehicle into position while you stay in command of speed. LR-Retrofit activates Park Assist on compatible Jaguar and Land Rover models through factory-compliant software coding within your vehicle’s Central Configuration File (CCF). We work with licensed JLR diagnostic tools and official calibration data. Your vehicle then parks with a level of precision that manual steering rarely matches.

What Park Assist Delivers

Park Assist supports two manoeuvre types. Parallel Park Assist handles kerbside gaps between two parked vehicles, which many drivers find the most demanding task of all. Perpendicular Park Assist handles bay spaces in car parks, where you reverse between two stationary vehicles. In both cases, the Parking Aid Module (PAM) evaluates the gap and confirms whether it provides enough clearance for your vehicle.

Once you accept the manoeuvre, the system controls the steering. You keep authority over the accelerator and brake on most platforms, so you decide exactly how fast the vehicle moves. The touchscreen displays your progress with step-by-step prompts, and the parking aid tones continue to report distance to nearby objects. Later platforms also manage drive and reverse selection and apply the brakes automatically when the situation requires it.

Park Exit reverses the process. It guides your vehicle out of a tight bay where forward visibility is limited. The system steers while you control speed, and Blind Spot Assist plus Reverse Traffic Detection monitor the traffic approaching from both sides.

Park Assist also integrates with the Surround Camera System where fitted. You view the manoeuvre from several angles while the system handles the steering geometry, which builds confidence in tight multi-storey car parks.

How the System Works

Ultrasonic sensors mounted in the front and rear bumpers measure the available space and report object distances to the PAM. The module then calculates the steering trajectory required to place your vehicle within the gap. During the manoeuvre, the PAM sends steering commands over the vehicle’s CAN network to the Electric Power Steering (EPS) system. The EPS applies the calculated steering angle continuously and adjusts it as the vehicle moves.

Where the platform supports automatic braking, the PAM also requests braking force from the Anti-Lock Braking System (ABS) and Electronic Stability Program (ESP). The Transmission Control Module handles drive and reverse selection on those platforms, which allows a fully managed manoeuvre.

JLR fits the required sensors, wiring and EPS hardware to most compatible vehicles at the factory. The restriction sits within the CCF and the PAM calibration rather than in the hardware. We modify the relevant parameters and confirm the correct module configuration, which unlocks the function without adding or replacing components.

Sensor Calibration

Accurate parking assistance depends on precise sensor alignment. We complete a calibration routine after coding so the PAM builds a correct model of your vehicle’s surroundings. This step also confirms that the ultrasonic sensors report consistent distances across the full detection range. Where a bumper has seen repair work or a sensor has been replaced, we verify alignment before we begin. Correct calibration delivers smooth trajectory calculation and reliable object detection in every manoeuvre.

System Requirements

• Front and rear parking aid sensors — required for space measurement and object detection.
• Electric Power Steering — required for automatic steering control.
• Touchscreen display — required for the Park Assist interface and guidance prompts.
• Anti-Lock Braking System and ESP — required for automatic braking on supported platforms.
• Compatible PAM software level — required for trajectory calculation functions.

Where your vehicle lacks a required component, LR-Retrofit supplies genuine JLR parts and completes the installation before coding.

Compatible Vehicles

LR-Retrofit activates Park Assist on a wide range of Jaguar and Land Rover vehicles. The following platforms typically support this retrofit:

Land Rover Models	Jaguar Models
Defender L663 (2020–present)	F-Pace X761 (2016–present)
Range Rover L405 / L461 (2013–present)	XF X260 (2016–present)
Range Rover Sport L494 / L461 (2014–present)	XE X760 (2015–present)
Range Rover Velar L560 (2017–present)	E-Pace X540 (2018–present)
Discovery L462 (2017–present)	I-Pace X590 (2018–present)
Discovery Sport L550 (2015–present)	F-Type X152 (2013–present)
Evoque L538 / L551 (2012–present)

Our team confirms your vehicle’s exact configuration before we begin. We check your VIN, PAM part number, sensor fitment and current CCF settings to build a tailored plan.

Activation Process

LR-Retrofit performs Park Assist activation through professional software coding. This approach delivers several clear advantages:

• No hardware installation required — the function uses your vehicle’s existing sensors, EPS and display hardware.
• Factory-compliant coding — we modify your vehicle’s CCF using licensed JLR diagnostic tools and official OEM data.
• Complete in under two hours — the process is fast, efficient and fully reversible.
• Full verification — we calibrate the sensors, scan for fault codes and test parallel and perpendicular manoeuvres before handover.

We complete the activation at our workshop or through remote coding, depending on your location and vehicle setup.

Why Choose LR-Retrofit

LR-Retrofit specialises in genuine Jaguar and Land Rover upgrades. We use original JLR software, licensed diagnostic tools and factory calibration data. Our team brings deep technical knowledge of JLR platforms from 2005 to the present. Every activation matches manufacturer specification and integrates cleanly with your vehicle’s existing configuration.

Park Assist pairs naturally with our Blind Spot Assist, Reverse Traffic Detection and Surround Camera activations. You can combine services during the same session and receive discounted package pricing.

Order Your Park Assist Activation

Take the next step toward simpler, more confident parking. Contact LR-Retrofit today to confirm compatibility for your Jaguar or Land Rover and schedule your Park Assist activation. Our team responds quickly and guides you through every step of the process.

Enquire now — your vehicle may already have everything it needs.

Note: Park Assist is a driver aid, not an autonomous parking system. Drivers must remain attentive, monitor the manoeuvre and maintain control of vehicle speed at all times. System effectiveness depends on sensor cleanliness, space dimensions and the position of surrounding objects.
