OEM-grade blind spot system retrofit for Land Rover and Jaguar. Add radar-based blind spot monitoring with mirror warning indicators and rear cross-traffic alert.
Product Overview
LR Retrofit supplies a complete blind spot system retrofit for Land Rover and Jaguar vehicles. This upgrade adds radar-based blind spot monitoring to your existing safety suite. The system detects vehicles in the adjacent lanes and illuminates a warning indicator in the corresponding side mirror. You gain an extra layer of awareness that helps you change lanes with confidence.
We use OEM-grade radar sensors that mount behind the rear bumper cover. The system integrates with the factory CAN bus and the existing side mirror assemblies. No aftermarket displays or switches remain visible. The result is a factory-fitted safety feature that operates seamlessly with your vehicle’s original electronics.
Key Features
- Radar-based blind spot monitoring for left and right sides
- Warning indicators in factory side mirror glass
- Rear cross-traffic alert during reverse manoeuvres
- Detection range up to 70 metres behind the vehicle
- Speed-dependent activation above 15 km/h
- Adjustable warning sensitivity through touchscreen menu
- Plug-and-play wiring with vehicle-specific connectors
- No permanent modification to bumper or mirror assemblies
You see a bright amber indicator in the mirror when a vehicle enters the blind spot. If you indicate to change lanes, the indicator flashes urgently to warn you. The system also alerts you to crossing traffic when you reverse out of parking spaces.
Performance Benefits
The blind spot system reduces the risk of side collisions and lane-change accidents. You receive a clear visual warning without taking your eyes off the road. The rear cross-traffic alert helps you spot approaching vehicles that you cannot see in the mirrors. You drive with greater confidence in heavy traffic and tight car parks.
Technical Specifications
| Sensor type | 24 GHz radar, two sensors |
|---|---|
| Detection range | Up to 70 metres |
| Detection angle | 150 degrees horizontal |
| Activation speed | Above 15 km/h |
| Warning output | Mirror glass indicator, audible chime optional |
| Integration | JLR CAN bus, body control module |
| Operating voltage | 12V DC |
| Operating temperature | -40°C to +85°C |
| Connector type | OEM-compatible 4-pin |
Compatibility
- Land Rover Range Rover (L405, L460)
- Land Rover Range Rover Sport (L494, L461)
- Land Rover Discovery 5 (L462)
- Land Rover Defender (L663)
- Land Rover Range Rover Velar (L560)
- Jaguar F-Pace (X761)
- Jaguar XF (X260)
Vehicles must have electric adjustable mirrors and the factory CAN bus architecture. LR Retrofit confirms exact compatibility from your VIN before dispatch. Models with existing blind spot monitoring do not require this kit.
Installation and Coding Support
We recommend professional installation. LR Retrofit supplies the complete hardware kit with radar sensors, mirror glasses with indicators, wiring looms, and mounting brackets. Our technical team provides remote coding support through JLR diagnostic tools. You update the Car Configuration File to activate the blind spot system. This enables the warning indicators and rear cross-traffic alert.
The installation follows the factory method. You mount the radar sensors behind the rear bumper cover. The mirror glasses with built-in indicators replace the standard glasses. The wiring routes along the existing vehicle harness. All connectors use factory pin-outs. No cutting or splicing of the vehicle harness is necessary.
Technical Note
The blind spot system communicates over the JLR CAN bus. The radar sensors transmit detection data to the body control module. The module illuminates the mirror indicators and triggers an audible warning where configured. LR Retrofit supplies the correct coding parameters for your model. The system operates independently of the parking sensors and rear view camera.
Package Contents
- Two radar sensors with mounting brackets
- Two side mirror glasses with integrated warning indicators
- Vehicle-specific wiring loom set
- Control module with pre-loaded firmware
- Installation and coding manual
Why Choose LR Retrofit
LR Retrofit focuses exclusively on JLR safety and electrical upgrades. Each kit receives final inspection before dispatch. We use only OEM-grade radar sensors and components. A 24-month warranty covers all parts. Our support team assists with coding, installation, and troubleshooting from start to finish.
Order and Delivery
Order the blind spot system retrofit today. We dispatch from stock within one business day. Worldwide shipping includes full tracking. Contact our team for a VIN-specific compatibility check before purchase.
