ClearSight Digital Rearview Mirror Retrofit Kit
Complete OEM-Grade System Restoration for Land Rover & Jaguar Vehicles
Product Overview
The LR-Retrofit ClearSight Digital Rearview Mirror system represents a comprehensive restoration solution for JLR vehicles originally equipped or optioned with this advanced safety technology. This genuine OEM retrofit kit delivers full factory functionality by integrating the sophisticated ClearSight camera display system into the vehicle's interior rearview mirror assembly.
Engineered to exact JLR specifications, this system transforms the conventional reflective mirror into a high-resolution digital display when reverse gear is selected. The roof-mounted camera provides an unobstructed, wide-angle view of the rear environment, significantly enhancing driver visibility and situational awareness. This restoration maintains complete electrical and aesthetic integration with the vehicle's existing architecture.
Technical Specifications
| Component | Specification |
|---|---|
| Display Type | High-Resolution LCD with Anti-Glare Coating |
| Display Resolution | 1280 x 480 Pixels (HD Quality) |
| Camera Sensor | Wide-Angle CMOS with Night Vision Enhancement |
| Field of View | 150° Panoramic Coverage |
| Mirror Function | Electrochromic Auto-Dimming with Compass Option |
| Activation Method | Automatic via Reverse Gear Signal or Manual Toggle |
| Power Requirements | 12V DC via Vehicle-Specific Harness |
| Communication Protocol | LIN Bus Integration or Direct Hardwiring |
| Camera Location | Roof-Mounted CHMSL Integration or Spoiler Mount |
System Features & Operational Benefits
Enhanced Rear Visibility
The ClearSight system eliminates visual obstructions caused by headrests, passengers, or cargo, providing an unimpeded digital view of the rear environment. This technology significantly improves safety during reversing maneuvers and general driving.
Seamless OEM Integration
Our retrofit kit maintains complete factory integration, utilizing existing vehicle wiring where possible and providing custom harnesses where required. The system operates exactly as JLR engineers intended, with automatic activation and intuitive controls.
Dual-Function Mirror Assembly
The assembly functions as both a conventional auto-dimming mirror and a digital display. Drivers enjoy the flexibility of traditional mirror reflection during normal driving and digital enhancement when needed.
Night Vision Enhancement
The camera system incorporates advanced light-sensitive technology that improves visibility in low-light conditions, providing clearer rearward vision during nighttime driving than conventional mirror reflection alone.
Vehicle Compatibility
This ClearSight retrofit kit supports multiple JLR platforms that originally offered this technology as factory or dealer-installed options. Compatibility verification requires checking your vehicle's build specification.
Range Rover (L405)
Model Years: 2013-2021
Requires: Camera activation harness
Range Rover Sport (L494)
Model Years: 2014-2022
Requires: LIN bus integration
Discovery 5 (L462)
Model Years: 2017-2023
Requires: Roof camera bracket
Velar (L560)
Model Years: 2018-2023
Requires: Full retrofit kit
Jaguar F-Pace (X761)
Model Years: 2016-2023
Requires: Camera module
Jaguar F-Type (X152)
Model Years: 2014-2023
Requires: Specialized wiring
Important Note: Full system functionality may require software configuration using JLR's SDD/Pathfinder diagnostic system. Some vehicles may need additional components based on factory wiring. Our technical team provides compatibility verification prior to purchase.
Complete Kit Components
Each LR-Retrofit ClearSight kit includes all necessary components for professional installation:
- ClearSight Mirror Assembly: Genuine JLR digital rearview mirror with integrated display
- High-Mount Camera Module: Roof-mounted wide-angle camera with weatherproof housing
- Vehicle-Specific Harness: Custom wiring harness with all required connectors
- Mounting Hardware: Complete bracket and fastener set for secure installation
- Technical Documentation: Comprehensive installation manual with wiring diagrams
- Activation Guide: Step-by-step configuration instructions for diagnostic tools
Installation & Configuration
We recommend installation by qualified technicians familiar with JLR electrical systems. The installation process follows factory service procedures:
- Remove existing interior rearview mirror and prepare mounting surface
- Install roof-mounted camera module in CHMSL area or roof spoiler
- Route camera cable through headliner to mirror location
- Connect vehicle-specific harness to power, ground, and signal circuits
- Install new ClearSight mirror assembly and secure all connections
- Activate system features using JLR diagnostic software
- Calibrate camera alignment and verify all functions
Each kit includes detailed technical documentation with vehicle-specific instructions. Our support team provides additional guidance for professional installers.
Owner Benefits
- Superior Safety Enhancement: The ClearSight system provides approximately 300% more rearward visibility than conventional mirrors, dramatically reducing blind spots and improving collision avoidance.
- Factory-Correct Restoration: This retrofit restores the vehicle to its intended specification, maintaining OEM quality and integration.
- Increased Resale Value: Vehicles with factory-installed advanced safety features typically command higher resale prices in the luxury market.
- Enhanced Driving Experience: Drivers gain confidence in maneuvering, parking, and general driving with improved rearward visibility.
- Professional Support: Access to LR-Retrofit's technical expertise ensures proper installation and functionality.
Restore Factory ClearSight Functionality
This comprehensive retrofit kit represents the definitive solution for adding JLR's advanced ClearSight technology to your vehicle. Regain the safety and convenience features that match your vehicle's luxury specification.
Contact our technical sales team for compatibility verification and professional installation guidance.
| Make Model | Discovery Sport 2021+ |
|---|
