Tyre Pressure Monitoring System (TPMS) Retrofit for Jaguar Land Rover
lr-retrofit.com supplies a complete Tyre Pressure Monitoring System (TPMS) retrofit for Jaguar Land Rover vehicles. Our engineers develop this direct TPMS kit to integrate with the existing JLR CAN bus architecture. You gain live pressure and temperature data in the instrument cluster without altering the original dashboard layout.
JLR-Specific Direct TPMS Technology
Each wheel sensor replaces the standard rubber valve stem. The sensor measures pressure and temperature every few seconds and transmits the data on the 433 MHz frequency. A dedicated receiver module connects to the vehicle’s medium-speed CAN bus. The module then feeds the data to the instrument cluster and the central body control module. This integration matches the factory behaviour of later Discovery, Range Rover and Defender models.
Why Retrofit a TPMS?
- Live tyre pressure monitoring reduces the risk of slow punctures and blowouts.
- Correct pressures extend tyre life and lower fuel consumption.
- Factory-style alerts appear in the instrument cluster.
- You keep the original JLR warning chimes and message centre text.
- The system supports both summer and winter wheel sets with a second sensor ID set.
Technical Integration on JLR Platforms
JLR models use a direct TPMS strategy. The receiver module sits behind the right-hand rear wheel arch liner on most vehicles. Our wiring loom plugs into the existing CAN junction. The kit includes the correct connectors for the model year. You do not need to cut or splice any factory wires. After installation, you code the module with a JLR approved diagnostic tool. The vehicle then displays individual pressures in the instrument cluster.
Compatible Vehicles
We configure this TPMS retrofit for the following JLR platforms:
- Discovery 3 (L319) and Discovery 4 (L319 facelift) without factory TPMS
- Range Rover Sport (L320) without factory TPMS
- Freelander 2 (L359) without factory TPMS
- Range Rover Evoque (L538) where the factory module is absent
- Defender (L663) models that left the factory without TPMS
If your vehicle already has the factory TPMS receiver but inactive sensors, we also supply individual sensors and coding support.
Kit Contents
- 4 OEM-quality TPMS sensors with metal valve stems
- 1 JLR-specific receiver module
- 1 vehicle wiring loom with factory connectors
- Mounting bracket and fixings
- Coding and installation manual
Installation and Support
Most competent DIY owners complete the installation in under two hours. The wheel sensors require tyre removal and refitting. We recommend professional tyre fitting for sensor installation. Once you fit the sensors, you pair them by driving the vehicle or by using a TPMS activation tool. Our support team provides remote coding assistance for the module.
Order Your JLR TPMS Retrofit
Order the lr-retrofit.com TPMS retrofit today. You receive the complete kit, coding instructions and lifetime technical support. Use the contact form for a compatibility check before purchase. We dispatch worldwide from our UK workshop.
