Park Assist

Short Description: Retrofit or update Park Assist on your Jaguar Land Rover. We install genuine sensors, program the Parking Aid Module (PAM), and calibrate the system for accurate front and rear parking guidance.

---

Overview

Park Assist makes parking easier and safer by alerting you to obstacles around your vehicle. Many Jaguar Land Rover models leave the factory with rear sensors only, while front sensors and the more advanced Active Park Assist remain available as options. Our service adds or updates these features to give you complete parking confidence. We work with genuine JLR components and factory diagnostic tools, so every installation looks and functions exactly as the original.

Whether you need a full retrofit of front and rear sensors, or simply want to activate the Active Park Assist feature on a vehicle that already has the necessary hardware, we handle every step. The result is a seamless, integrated system that displays on your touchscreen and instrument cluster.

What This Service Includes

Parking Aid Module Programming

The Parking Aid Module (PAM) controls all parking sensor inputs and alerts. We read the current configuration from your vehicle, identify which sensor positions are present, and program the PAM to recognise them. We also adjust the warning tone volume, the minimum and maximum detection distances, and the display behaviour to match your preferences. If your vehicle previously had only rear sensors, we update the PAM configuration to add front sensor support without replacing the module.

Genuine Sensor Installation

For vehicles that require additional sensors, we install genuine JLR ultrasonic sensors in the correct factory positions. Front sensors fit into the bumper mouldings, while additional rear sensors may occupy the outer positions for better coverage. We paint the sensors to match your vehicle’s body colour and use the original mounting brackets and harness connectors. Every sensor connects to the existing PAM wiring loom, with no cutting or splicing required.

Active Park Assist Activation

Active Park Assist takes the system one step further by automatically steering your vehicle into parallel or perpendicular parking spaces. This feature requires additional side sensors and a software upgrade to the PAM and the Electric Power Steering module. We install the side sensors, update the module software, and activate the feature through the vehicle’s configuration. Once complete, you activate Active Park Assist with a dashboard button, and the system guides you through the parking manoeuvre.

Touchscreen and Instrument Cluster Integration

We update the infotainment system and instrument cluster to display the parking sensor graphic correctly. The touchscreen shows a real-time view of the vehicle with colour-coded distance indicators. The instrument cluster displays the same information in a simplified format. We configure both displays to match the factory behaviour, including the automatic activation when you select reverse gear.

Calibration and Road Test

After programming and installation, we perform a full calibration of the parking sensors. This ensures accurate distance measurement and reliable obstacle detection. We test the system in a controlled environment with known obstacles at various distances, then conduct a road test to verify that the sensors operate correctly at real-world parking speeds. You receive a report confirming the calibration results and the system’s performance.

Technical Details for JLR Enthusiasts

• Modules involved: Parking Aid Module (PAM), Central Junction Box (CJB), Body Control Module (BCM), and Electric Power Steering (EPS) for Active Park Assist.
• Sensor type: Genuine JLR ultrasonic sensors, 40 kHz frequency, with body-colour painted finish.
• Diagnostic platform: JLR SDD (Symptom Driven Diagnostics) or Pathfinder, using OEM calibration files.
• Vehicle compatibility: Range Rover, Range Rover Sport, Discovery 4/5, Velar, Evoque, Jaguar XE, XF, F-Pace, E-Pace, and I-Pace (model dependent).
• Time required: Typically 1–2 hours for programming and calibration. Full sensor retrofit may take up to 4 hours.
• Warranty impact: Genuine JLR parts and factory programming do not affect the vehicle warranty. We provide a 12-month warranty on all installed components.

Why Choose LR Retrofit

We specialise exclusively in Jaguar Land Rover vehicles. Our technicians understand every variation of the parking system across the model range. We use only genuine JLR parts and the same diagnostic tools as franchised dealers. Our installations maintain the factory appearance, and every function works exactly as the manufacturer intended. You receive a written report documenting the work performed and confirming that no fault codes remain.

For customers who cannot visit our workshop, we offer remote programming support. If your vehicle already has the sensors installed but the PAM requires configuration, we can often perform the programming remotely using a pre-configured OBD interface. Contact us to check remote programming availability for your model.
