Overview: System-Level Engineering for the AJ133

VelocityAP approaches the JLR 5.0L supercharged V8 as an integrated platform, not a collection of bolt-on parts. The company develops ECU calibration, pulley drive ratios, intake airflow, and exhaust hardware together, then validates the combination through dyno testing, road logging, and real-world data acquisition[reference:0]. This product page presents the VelocityAP custom power upgrade in its Stage 1, Stage 1+, and Stage 2 configurations for the AJ133 supercharged engine.

Factory JLR delivers this engine in several ratings, typically 525hp/625Nm or 575hp/700Nm depending on model and market[reference:1]. VelocityAP calibration and pulley hardware unlock the headroom JLR leaves in the production file while preserving factory safety strategies, drivability, and emissions compliance logic.

Engine Platform: AJ133 5.0L Supercharged V8

The AJ133 is a 90-degree all-aluminium V8 with a bore of 92.5 mm and a stroke of 93.00 mm, giving it a nearly square architecture that supports strong low-end torque and high-rpm breathing. The supercharged variant runs a 9.5:1 compression ratio and mounts an Eaton sixth-generation TVS1900 roots-type twin-helix supercharger in the vee, driven from the crankshaft by a dedicated secondary belt. JLR fits the TVS1900 across the supercharged AJ133 range, and the supercharger drive ratio directly controls boost pressure and mass airflow.

VelocityAP works with this architecture rather than against it. The calibration recalibrates torque management, direct-injection fueling, ignition advance, and supercharger bypass behavior to match the hardware fitted. The pulley system then increases supercharger speed to raise boost within the airflow and thermal limits of the TVS1900 platform.

Stage Comparison and Tested Output

Output figures reflect VelocityAP’s tested configurations on the AJ133 platform[reference:4]. 200-cell sport catalysts are available as a supporting hardware option for Stage 2 and above.

Hardware Detail: How the Pulley System Raises Boost

The TVS1900 produces boost in proportion to its drive speed. VelocityAP increases drive speed through two complementary components, and the ECU calibration manages fueling and safety parameters to support the higher airflow.

VelocityAP Oversized Crank Pulley

The oversized crank pulley enlarges the driving pulley at the crankshaft, increasing the overall drive ratio. In VelocityAP’s own testing, the crank pulley adds roughly 3.5 PSI of boost and raises mass airflow, and the calibration maintains proper fueling and safe operating margins[reference:5]. The crank pulley also delivers more overdrive than the upper supercharger pulley alone, which makes it the primary hardware step for increasing boost on the V8[reference:6].

VAP Griptec Upper Supercharger Pulley

The upper pulley reduces diameter at the supercharger input, raising blower speed further. VelocityAP uses a two-piece design with Griptec micro-texture on the pulley surface. The micro-texture improves belt traction and reduces slip under high load, a critical factor as blower speed and drive torque increase[reference:7]. VelocityAP offers both pulleys individually or in combination, and the calibration matches the specific hardware configuration fitted to the vehicle[reference:8].

Calibration Strategy: Integrated, Not Isolated

VelocityAP develops ECU and TCU calibrations to complement the pulleys, intake, and catalysts as a system. The company continuously monitors airflow, fueling, knock resistance, and thermal behavior through proprietary data logging, then refines the calibration for sustained performance rather than a single peak number[reference:9].

On the AJ133, the calibration manages torque delivery through the ZF 8HP transmission. VelocityAP also offers TCU tuning that raises torque allowance and adjusts shift behavior to match the engine’s new output character, delivering faster and smoother upshifts and downshifts[reference:10].

Stage 1 operates as a calibration change only and requires no physical engine modification. The original factory file remains restorable, which makes Stage 1 the reversible entry point into the VelocityAP ecosystem.

Supporting Hardware for Stage 2

Stage 2 adds the Griptec upper pulley and 200-cell sport catalyst downpipes. High-flow 200-cell catalysts from HJS flow up to 93–95% of a straight pipe in most applications while still providing enough emissions scrubbing to prevent a check-engine light[reference:11]. VelocityAP calibrates for the reduced backpressure and changed airflow. For vehicles running aggressive pulley ratios under sustained heat and load, VelocityAP also offers an upgraded supercharger belt tensioner that re-routes the belt for greater contact on the upper pulley and reduced slip.

Vehicle Compatibility and Ordering

This upgrade applies to JLR vehicles fitted with the AJ133 5.0L supercharged V8. Because JLR produced this engine across multiple model years, platforms, and factory ratings — including supercharged Range Rover, Range Rover Sport, Range Rover Sport SVR, and Jaguar F-Type variants — compatibility depends on the exact VIN and current calibration[reference:12]. Provide your VIN during ordering, and the team confirms the correct target file and hardware configuration before dispatch.

Final stage selection depends on fuel quality, supporting modifications, and intended use. Stage 1 suits owners seeking reversible calibration gains on a standard vehicle. Stage 2 suits owners who want the full dual-pulley and downpipe combination with supporting calibration.

Why Choose the VelocityAP 5.0SC V8 Upgrade

• System-level validation: Software and hardware undergo joint development and testing, not isolated part-by-part claims[reference:13].
• Tested output figures: Stage gains come from dyno and road development on the AJ133 platform.
• Griptec belt traction: The upper pulley micro-texture reduces slip at elevated blower speeds, protecting consistency under load[reference:14].
• TCU integration: Transmission calibration raises torque allowance and aligns shift behavior with the engine’s new character[reference:15].
• Scalable path: Start with Stage 1 calibration and add crank pulley, upper pulley, and downpipes as your goals evolve.

Configure Your 5.0SC V8 Upgrade

Select your stage, confirm compatibility with your VIN, and build the calibration and pulley combination that matches your JLR vehicle. For Stage 2 and supporting hardware enquiries, contact LR-Retrofit with your model year and current factory output.

Enquire with VIN for compatibility
