Genuine JLR Cabin Air Ionisation – PM2.5 Air Quality Retrofit

Replace your standard pollen filter with a factory‑developed air purification system that integrates directly into your Land Rover’s climate control. A high‑voltage bipolar ioniser and an upgraded PM2.5‑certified particulate filter work together to capture fine dust, inactivate airborne pathogens and remove unpleasant odours — all without altering dashboard appearance or blower performance. After programming the Car Configuration File, your infotainment screen displays a dedicated purification interface, giving you real‑time air quality information and one‑touch control.

How the System Cleans Your Cabin Air

The ioniser sits in the ventilation duct immediately downstream of the blower motor. When the HVAC control module activates it, a bank of needle‑point electrodes generates a balanced stream of positive and negative ions. These charged clusters attach to airborne particles — soot, pollen, mould spores, bacteria and viruses — causing them to agglomerate and fall out of suspension. At the same time the ions break down volatile organic compounds (VOCs) that cause lingering smells from pets, damp clothing or food.

• Bipolar ionisation — produces both polarities simultaneously, neutralising contaminants within the entire cabin volume.
• PM2.5 high‑efficiency filter — synthetic multi‑layer media with activated carbon layer captures ≥ 95 % of particles ≤ 2.5 µm (ISO 16890‑1 ePM2.5 certified).
• HVAC‑managed automatic recirculation — closes the fresh‑air flap whenever the vehicle’s air quality sensor detects high nitrogen dioxide or carbon monoxide levels outside.
• Seamless integration — no extra switches; the purification menu appears on Pivi Pro, InControl Touch Pro or the 10‑inch infotainment screen just like a factory option.

Technical Data

Retrofit Kit Contents

You receive a pre‑terminated harness, genuine Land Rover ioniser module, bracket and the PM2.5 filter insert. All connectors match the factory blower housing. Colour installation guides cover trim removal, wiring routing and the CCF coding procedure.

• JLR certified bipolar ioniser with mounting frame
• PM2.5 cabin filter (direct replacement for standard pollen filter)
• Vehicle‑specific wiring harness, fused inline, with weather‑proof connectors
• LIN‑bus interface lead
• Fitting instructions with torque values and circuit diagrams
• Remote CCF coding support to unlock the air‑quality screen on your touchscreen

Compatible Land Rover Models

We verify your VIN for fitment. The system fits every series‑production Land Rover with automatic climate control and a pollen filter housing that accepts the thicker PM2.5 element:

• Range Rover L460 (2022–)
• Range Rover L405 (2018–2022)
• Range Rover Sport L494 (2018–2022)
• Discovery 5 L462 (2017–)
• Range Rover Velar L560 (2018–)
• Defender L663 (2020–)
• Range Rover Evoque L551 (2019–)
• Discovery Sport L550 (2019–)

Real‑World Benefits

On a day when outside air pollution pushes the PM2.5 index beyond 150 µg/m³, your cabin air remains below 12 µg/m³, according to independent measurement. Allergy sufferers notice dramatically fewer sneezing fits after a pollen‑laden walk. The ioniser even suppresses the stale smell that builds up overnight in a sealed vehicle, so you start every journey in freshness. Because the system is a factory‑integrated option, you gain full dealer‑level diagnostability and retain your vehicle’s resale appeal.

Order your kit today. Forward your VIN to our team, and we confirm compatibility, supply a bespoke quotation and schedule installation within one business day.
